Two clear quartz crimp top vials of varying heights, showcasing the transparent high-purity fused silica material against a blue background
1/6

High Purity Quartz Crimp Top Vials | Fused Silica Sample & Reaction Vials

$0.00

Direct from Manufacturer & Customization Supported

Made to Order with Your Drawings

Contact us for a shipping quote

Whatsapp

Quartz Crimp Top Vials

High Optical Transmission, Excellent Transmittance, High Clarity, High Light Transmission.

High Temperature Resistance, Excellent Thermal Stability, Heat Resistant up to 1200°C.

Wide Range of Sizes, Full Specifications Available, Various Sizes & Specs, Comprehensive Rang

Acid & Alkali Resistant, High Chemical Resistance, Excellent Corrosion Resistance.

Product parameters

Product Name Fused Quartz Standard Taper Stopper
Material High-Purity Fused Silica (Quartz Glass)
Key Features
  • Robust and Optically Clear: Thick-walled construction for durability with excellent transparency.

  • Superior Thermal Resistance: Withstands high temperatures and thermal shock.

  • High Light Transmittance: Optimal clarity across a wide spectral range.

  • Chemically Inert: Resistant to most acids and corrosive substances, ensuring sample integrity

Applications

This clamp-top quartz bottle is primarily designed for:

  • Demanding Chemical Experiments: Ideal for reactions in high-temperature or corrosive environments.

  • Industrial Processes & Reactions: Suitable for various industrial applications requiring high-purity, heat-resistant vessels.

  • Secure Sample Storage: Provides a reliable solution for storing sensitive samples.
    The fused quartz material offers exceptional resistance to high temperatures and chemical corrosion.The clamp-top design ensures a secure seal and facilitates easy connection to other laboratory apparatus.

Quartz Performance Table

Mechanical Properties Typical Value Thermal Properties Typical Value Electrical Properties Typical Value
Density 2.2 g/cm³ Softening Point 1780°C Electrical Resistivity 7 x 107 Ω·cm
Compressive Strength 1100 MPa Annealing Point 1250°C Dielectric Strength 250 - 400 kV/cm
Flexural Strength 67 MPa Specific Heat (20-350°C) 670 J/kg·°C Dielectric Constant 3.7 - 3.9
Tensile Strength 48 MPa Thermal Conductivity (20°C) 1.4 W/m·°C Dielectric Absorption Coefficient <1 x 10-4
Poisson's Ratio 0.14 - 0.17 Refractive Index 1.4585 Dielectric Loss Tangent <1 x 10-4
Young's Modulus 72000 MPa Coefficient of Thermal Expansion 5.5 x 10-7 /°C
Shear Modulus 31000 kPa Working Temperature 1750 - 2050°C
Mohs Hardness 5.5 - 6.5 Short-Term Service Temperature 1300°C
Strain Point 1280°C Continuous Service Temperature 1100°C

Full specification

Comprehensive Specifications & Diverse Options

Heat resistance

Secure Clamp-Top Design for Excellent Airtightness

High Transmittance

Full Product Range & Customization Services
